30 x 50 house plan, north facing, as per Vastu
The extra depth of a 30x50 plot, paired with a north-facing entrance.
Sample 30x50 north-facing 3 BHK plan
What fits on a 30x50 plot
With the standard setbacks this planner uses — 4 ft on the road side and 2 ft on the other three sides — a 30 × 50 ft plot leaves a buildable rectangle of 26' × 44', or about 1,144 sq ft of the 1,500 sq ft plot.
The generated layout uses 1,144 sq ft of that as ground-floor built-up area, of which about 438 sq ft is open living and dining space.
Setback rules come from your local municipal byelaws — change them in the planner and every figure above recalculates for your plot.
Achievable room sizes on a 30x50 plot
Every figure below is the solved interior dimension from the generated layout — wall face to wall face, exactly as printed on that drawing. Nothing here is a rule of thumb.
| Room | Size | Area |
|---|---|---|
| Master Bedroom | 11'7" x 11'7" | 134.7 sq ft |
| Bedroom 2 | 11'4" x 10'1" | 114.5 sq ft |
| Bedroom 1 | 11'4" x 9'9" | 110.3 sq ft |
| Kitchen | 7'4" x 13'5" | 98.3 sq ft |
| Utility | 7'4" x 4'3" | 31 sq ft |
| Bathroom 1 | 6'2" x 4'9" | 29.7 sq ft |
| Bathroom 2 | 6'2" x 4'9" | 29.7 sq ft |
| Bathroom 3 | 4'9" x 6'2" | 29.7 sq ft |
| Pooja Room | 3'5" x 3'11" | 13.4 sq ft |
| Living + dining | open plan | 438 sq ft |
Vastu notes for a 30x50 north-facing plot
As with the east-facing version of this plot size, the additional depth compared to a 30x40 mainly benefits the southwest master suite and gives room for a genuine second bedroom along the west or south wall. What's specific to the north-facing case is the living area's placement: sitting off the entrance along the north wall, it has more real width to work with on a 30x50 plot than a 30x40, which means it can comfortably serve as both a living and a dining area without feeling like two functions squeezed into one room. The northeast corner, as always, benefits from staying open — on a plot this size, that's genuinely achievable without sacrificing anything else in the layout.
Get this plan for your own 30x50 plot
Start with 30 × 50 ft, north-facing and 3 BHK already filled in — then change anything that doesn't match your plot.
30x50 north-facing plans: common questions
Does a north-facing 30x50 plot support a bigger living room than 30x40?
Yes, the extra depth typically translates most directly into more living/dining space, since the core bedroom and kitchen zones don't need to grow proportionally.
Where should a home office or study go on this plot?
West or south are the classically acceptable directions for a study, and the extra depth of a 30x50 plot makes room for one without displacing a bedroom.
Is a north-facing 30x50 a good choice for a joint family?
It's a reasonable middle ground — more room than a 30x40 without the cost step up of a 40x60, though a joint family with more members may still prefer the larger plot.
