36 x 50 house plan, north facing, as per Vastu
The same generous 1,800 sq ft footprint as the east-facing version, with a north-facing entrance.
Sample 36x50 north-facing 3 BHK plan
What fits on a 36x50 plot
With the standard setbacks this planner uses — 4 ft on the road side and 2 ft on the other three sides — a 36 × 50 ft plot leaves a buildable rectangle of 32' × 44', or about 1,408 sq ft of the 1,800 sq ft plot.
The generated layout uses 1,408 sq ft of that as ground-floor built-up area, of which about 614 sq ft is open living and dining space.
Setback rules come from your local municipal byelaws — change them in the planner and every figure above recalculates for your plot.
Achievable room sizes on a 36x50 plot
Every figure below is the solved interior dimension from the generated layout — wall face to wall face, exactly as printed on that drawing. Nothing here is a rule of thumb.
| Room | Size | Area |
|---|---|---|
| Master Bedroom | 15'1" x 11'1" | 167.2 sq ft |
| Bedroom 2 | 12'10" x 10'4" | 132.6 sq ft |
| Bedroom 1 | 12'10" x 9'11" | 127.8 sq ft |
| Kitchen | 7'2" x 13'5" | 96.3 sq ft |
| Bathroom 3 | 4'9" x 7'5" | 35.3 sq ft |
| Bathroom 1 | 7'2" x 4'9" | 34.4 sq ft |
| Bathroom 2 | 7'2" x 4'9" | 34.4 sq ft |
| Utility | 7'2" x 4'3" | 30.3 sq ft |
| Pooja Room | 3'3" x 4'5" | 14.4 sq ft |
| Living + dining | open plan | 614 sq ft |
Vastu notes for a 36x50 north-facing plot
With the road to the north, the greater 36-foot width gives the living area real room to spread along the entrance wall — on a plot this width, the living and dining space can sit side by side rather than one behind the other, both still within the classically acceptable northern and eastern portions of the layout. The kitchen and master bedroom hold their usual southeast and southwest positions, each with the same benefit of the extra depth as the east-facing version: a genuinely complete master suite, and a kitchen with its own separate utility area rather than a shared corner. The northeast corner, wide enough here to be a real feature rather than a narrow gap, is worth treating as more than an afterthought — a small open courtyard or a well-lit entry space does real justice to what this corner is meant to represent.
Get this plan for your own 36x50 plot
Start with 36 × 50 ft, north-facing and 3 BHK already filled in — then change anything that doesn't match your plot.
36x50 north-facing plans: common questions
Does a north-facing 36x50 plot suit a family that entertains often?
Yes — the wider plot makes a genuinely spacious combined living/dining area near the entrance realistic, which suits frequent guests well.
Can the northeast corner be a real courtyard on this plot size?
Often yes, given the extra width — it's one of the more satisfying uses of the northeast zone at this plot size.
Is this plot size better suited to a single floor or a duplex?
Both work well; the width and depth here comfortably support a single expansive floor or a duplex with more generous rooms per floor than a narrower plot would allow.
